WAGO Signal Conditioners and WAGO Isolation Amplifiers

Isolate, amplify, filter and convert: WAGO’s signal conditioners and WAGO's isolation amplifiers handle a large number of functions in various application areas and provide secure and error-free signal transmission – thanks to a comprehensive range of approvals for worldwide applications. The focus is on usability and absolute reliability.

WAGO’s signal conditioners and isolation amplifiers keep a uniform profile within cabinets. This allows easy commoning of the supply voltage, eliminating the need for time-consuming wiring of individual components.

Your Benefits:

Calibrated switching between measurement ranges to always ensure equal precision
Input/output response simulation (2857 Series)
Can be used under extreme environmental conditions (−40 … +70°C)
Safe isolation per DIN EN 61010-1
Intuitive configuration via software, app, display, DIP or push/slide switch

Discover Our Range of Signal Conditioners and Isolation Amplifiers

Isolation Amplifiers

Isolate, amplify, filter or convert: WAGO’s isolation amplifiers handle a large number of functions in industrial applications and provide secure and error-free signal transmission.

The range of isolation amplifiers provides the right solution for every application:

With a power supply: isolation amplifiers (permanently configured), isolation amplifiers (configurable), universal isolation amplifiers, bipolar isolation amplifiers, repeater power supplies, signal splitters
Without a power supply: passive isolators, loop-powered isolators

Your benefits with WAGO's isolation amplifiers:

Galvanic isolation between input/output/power supply
Zero and span adjustment to compensate for error or signal shifts
Switchable filter function to prevent signal interference
Reliable protection of the input circuit against overcurrent (857-409, 857-402, 2857-401)
A digital signal output (DO) reacts to freely configurable measurement range limits (this allows use as a threshold value switch – with activation/deactivation delay).

Show product list

Frequency Signal Conditioners

WAGO’s frequency signal conditioners record 0.1 kHz to 120 kHz signals from NAMUR, NPN or PNP sensors and convert the frequency into an analog standard signal.

Your benefits with WAGO's frequency signal conditioners:

Signal acquisition from NAMUR, NPN or PNP sensors
Frequency range: 0.1 … 120 kHz
Fault signaling: Wire break/short-circuit detection for NAMUR proximity sensors
Signaling measurement range underflow/overflow

Show product list

Temperature Signal Conditioners

With WAGO’s temperature signal conditioners, signals from Pt, TC, Ni, KTY and RTD sensors and resistors can be recorded and converted into an analog standard signal on the output side. Whether a resistive temperature device or a thermocouple is used depends on factors such as the maximum temperature range, the installation’s environment and the required measurement accuracy:

Resistive temperature device (RTD): Temperature range up to 850°C, high accuracy
Thermocouple (TC): Temperature range up to 2320°C, better response time

The benefits of our temperature signal conditioners for you:

Signal acquisition of Pt, TC, Ni, KTY and RTD sensors and resistors up to 4.5 kΩ (e.g., Pt100 sensors)
2-, 3- and 4-wire connection technology
Fault signaling: Wire break/short-circuit detection of the sensor
Signaling measurement range underflow/overflow

Show product list

Threshold Value Switches

WAGO’s threshold value switches monitor various measurement signals such as temperature, current or voltage. If a value falls above or below a limiting value setting, emergency stops or alarms can be triggered, for example. In addition to threshold value switches for analog signals, WAGO also offers RTD threshold value switches for resistance temperature sensors and potentiometers, as well as TC threshold value switches for thermocouples, allowing both signal monitoring and measurement.

Your benefits with WAGO's threshold value switches:

Input/output response simulation (2857 Series)
Relays as threshold value switches (e.g., activation/deactivation delay)
A digital signal output (DO) reacts to freely configurable measurement range limits (this allows use as a threshold value switch – with activation/deactivation delay).

Show product list

Potentiometer Signal Conditioners

WAGO’s potentiometer signal conditioner records resistance signals (e.g., from potentiometers) and converts them into a standard analog signal.

Your benefits with WAGO's potentiometer signal conditioners:

Signal acquisition from potentiometers and resistors
Automatic potentiometer identification
Configurable input and output parameters
A digital signal output (DO) reacts to freely configurable measurement range limits (this allows use as a threshold value switch – with activation/deactivation delay).

Show product list

Current, Voltage and Power Signal Conditioners

Besides current and voltage signal conditioners which record DC and AC currents and voltages, this impressive range also includes a power measurement module that can measure current and voltage in parallel, convert them to power and output them as an analog standard signal. Additionally, WAGO’s signal conditioner for Rogowski coils offers a solution for retrofitting existing systems. Thus it is not necessary to disconnect the live conductor. Das 3-Phasen-Leistungsmessmodul ermöglicht die Messung relevanter Parameter, wie Spannung, Strom, Leistung und Oberwellen im dreiphasigen Versorgungsnetz, direkt im Schaltschrank.

The benefits of our current, voltage and power signal conditioners for you:

Signal acquisition of DC and AC voltages up to 300 VAC/VDC using modules that are just 6 mm wide
AC currents up to 4000 A via Rogowski coil
Switchable filter function to prevent signal interference
A digital signal output (DO) reacts to freely configurable measurement range limits (this allows use as a threshold value switch – with activation/deactivation delay).

Show product list

3-Phase Power Measurement Modules

With the WAGO three-phase power measurement module in a DIN-rail-mount enclosure, WAGO offers the ideal solution – remotely from the control level – to measure currents and voltages in a three-phase supply network. Measured variables such as active/apparent/reactive power, energy consumption, power factor, phase angle and frequency can be accessed via Modbus® interface. Two integrated RJ-45 sockets streamline the interconnection of up to 32 devices.

Your Benefits:

Measurement via current transformers or Rogowski coils › Flexible selection of upcoming measurement tasks
Slot for microSD cards: Fast and secure mobile measurement, including recording
Compact device in DIN-rail-mount enclosure: Saves space used for building technology
Digital signal output as pulse output (pulses/KWh are configurable) › Permanent energy consumption monitoring

Show product list

Product News

The 3-in-1 Solution – in One Device

New 1-Phase Power Measurement Module for Current, Voltage and Power Measurement

The new single-phase power measurement module is a true multi-talent that directly measures both DC and AC currents up to 8 A, as well as DC and AC voltages up to 500 V. Furthermore, measured variables such as current, voltage, all types of power (3-in-1) and many more can be flexibly configured and evaluated – in the configuration software or directly on the device display. Therefore, this new module allows many current and voltage measurement requirements to be met in both industrial and transportation applications.

It also monitors, reports and displays signal statuses with up to two switching thresholds and provides these statuses to a higher-level PLC via an analog or serial interface. For use of this power measurement module as a current, voltage or power threshold switch, a relay and digital output are integrated.

Your Benefits:

Display connection for display and configuration
Simulation of input/output response for quick start-up
Additional digital signal output for configured measurement range limits

Configuration options

Intuitive configuration via software, app or display

Interface Configuration Software

The signal conditioners are all user-friendly and easy to configure using WAGO's interface configuration software.

Simulation of input and output parameters (2857 Series)
Automatic module recognition
Configuration and visualization of process values
Paramentierung des digitalen Schaltausgangs (Grenzwertfunktionalität)
Communication via WAGO USB Service Cable (750-923) or WAGO Bluetooth^® Adapter (750-921), pluggable on both series

Download free of charge

Configuration Display

WAGO's 2857-0900 Removable Display can be quickly and easily attached to the housing. This unique feature includes an innovative touch panel for intuitively configuring devices. The multicolor display changes between orange, red, green or white depending on the 2857 Series’ current status. Integrated capabilities, such as the copy function, can transmit stored configuration data from one device to another of the same type. Passwords for protecting configured data may be assigned to prevent unauthorized access and changes.

Can be easily plugged into signal conditioners
Touch function through capacitive operating environment
Automatic module recognition
Configuration and visualization of process values
Copying configuration data from device to device

Show product list

Configuration App

The free JUMPFLEX^®-ToGo App brings the power of PC-based configuration software to your Android mobile device.

Configuration of input and output parameters with a stroke of the finger
Simple display of configuration data and current value
Communication via WAGO Bluetooth^® Adapter (750-921)

Download free of charge

Discover Products

Learn more about this topic

.

All Products

Discover all our signal conditioners and isolation amplifiers.
