Small lever, big effect

One look, one click – terminating conductors using a lever with WAGO PCB terminal blocks and pluggable connectors is so quick and easy, safe and intuitive.

Why conductor termination with a lever?

Tool-free conductor terminations

Fast and easy wiring – without needing any tools or a third hand at all. The lever technology of the WAGO PCB Terminal Blocks and Pluggable Connectors makes it possible! A real relief for users and installers, especially in the field. Because the conductor can be terminated in no time without tools.

Reliable conductor termination

Reliability you can see – The lever of the WAGO PCB Terminal Blocks and Pluggable Connectors make it possible. If the lever is open, the clamping point is open; if the lever is closed, the clamping point is also closed. This gives users and installers certainty when terminating conductors.

Intuitive conductor termination

Intuitive conductor termination – thanks to levers! Because operating a lever is self-explanatory. This makes tool-free wiring of the WAGO PCB Terminal Blocks and Pluggable Connectors not only quick, but also intuitive – and that worldwide in every area of application!

Application Examples and Things to Know

Our WAGO experts provide information on all aspects of WAGO PCB Terminal Blocks and Pluggable Connectors about handling and areas of application, and offer examples and applications.
