Lighting Management

WAGO Lighting Management is a highly sophisticated solution for lighting control in large spaces such as production facilities and warehouses. Using a combination of predefined hardware and user-friendly software, WAGO offers a lighting management system that facilitates the design and commissioning of new lighting systems while providing numerous additional advantages for their operation.

WAGO Lighting Management:

  • Configuring Instead of Programming

  • Siplified Usage and Commissioning

  • Modern HTML 5 Graphical User Interface

Lighting Management with WAGO

The Intelligent Solution for Lighting Controllers

Overview of Functions

Lighting Management from WAGO provides the following functions:

  • Optimal lighting control through intelligent regulation and management, based, for instance, on switching and dimming
  • Constant light control, daylight control, Human Centric Lighting (HCL), time function etc.
  • Predefined hardware, including interfaces for DALI, EnOcean, KNX and predefined software
  • Energy consumption data acquisition; comprehensive diagnostic and maintenance options
  • Color temperature control (HCL) with additional curves for the dimming value and setpoint (lux)
  • Time switching program with a room function selection option for each schedule entry


Stay in Control of Your System

Modern lighting management offers more than mere reductions in energy and costs – it combines cost-efficiency and resource conservation with user comfort and flexibility. WAGO Lighting Management is a proven solution based on predefined hardware and preconfigured software, which greatly simplifies planning, commissioning and operation.

The basic idea: WAGO Lighting Management is oriented toward the different lighting requirements that apply in warehouses and production facilities. For example, a production facility is divided into virtual rooms in which the light can be flexibly adapted. Each virtual room receives signals from sensors and actuators in order to automatically set the appropriate light intensity. Virtual rooms allow both conversions and remodeling to be implemented quickly and simply via Web configuration.

High-Quality Hardware

The hardware side is based on WAGO’s new PFC200 Controller and DALI-2 Module from the WAGO I/O System 750. Each module can integrate up to 64 DALI lights, 16 DALI sensors and 16 DALI transmitters into the system. Since the number of I/O modules can vary, WAGO Lighting Management can be used for small production facilities or large logistics centers. Additional I/O modules can also be linked to the controller, such as 3-Phase Power Measurement Modules for energy measurement, a module for GPS-based time synchronization or a radio receiver module for EnOcean radio switches.


The Best Hardware for Your Lighting Management System

State-of-the-Art Software

However, the pre-programmed application and easy configuration via a Web-based interface are what really make WAGO Lighting Management a powerful and user-friendly solution. During both commissioning and operation, all settings can be performed with the click of a mouse – no programming required. Since the graphical user interface can be accessed via HTTPS and a standard browser, there is no need for local software installation. The Web visualization, based on HTML 5, makes this work especially convenient. Batch processing with Microsoft Excel via export/import complements this functionality. All configuration settings and parameters can be saved and restored. The values can be forwarded to a higher-level building control system or to a production control center via Modbus TCP/IP. On the input screen, dialogs are pre-populated with default settings for basic parameters, and operating states are displayed. An optional user interface for operation and monitoring allows state-of-the-art visualization and operation of the entire lighting system via mobile devices such as smartphones and tablets.

WAGO Lighting Management in Use

{ "id": "comp_0000644M", "headline": "Video Tutorials", "duration": "32:23", "videos": [ { "uid": "item_000064YZ", "videoId": "12yExMjttFnhPDLqh2Xacy", "caption": "<p>In this introduction, we will look at the configuration interface of WAGO Lighting Management and review its basic functionalities.</p>", "subtitleLanguage": "", "hostedOnTwentyThree": false, "imageUrl": "https://wagovideo.akamaized.net/public/videos/12yExMjttFnhPDLqh2Xacy/thumbnails/active?quality=1080p&cache-buster=969861&file-name=349616.3634.1080p.jpeg", "title": "<p>Part 1 – Introduction</p>", "duration": "3:25" } ,{ "uid": "item_000064Z0", "videoId": "E7iDxqwbFJYb57Q6D5cY1a", "caption": "<p>In this video, we will show you how to document and archive your configuration.</p>", "subtitleLanguage": "", "hostedOnTwentyThree": false, "imageUrl": "https://wagovideo.akamaized.net/public/videos/E7iDxqwbFJYb57Q6D5cY1a/thumbnails/active?quality=1080p&cache-buster=72dc58&file-name=349617.4157.1080p.jpeg", "title": "<p>Part 2 – Documentation Options</p>", "duration": "1:59" } ,{ "uid": "item_000064Z1", "videoId": "93R2ap1K8mzDmwveXBWsGZ", "caption": "<p>In this video, we explain the simple integration of KNX touch sensors within WAGO Lighting Management.</p>", "subtitleLanguage": "", "hostedOnTwentyThree": false, "imageUrl": "", "title": "<p>Part 3 – Connection of KNX Touch Sensors</p>", "duration": "4:03" } ,{ "uid": "item_000064Z2", "videoId": "FLeZ96_8FjFTWGcXz2XSqV", "caption": "In this video, we explain the color temperature control options. For this function, date-dependent HCL curves (HCL) and/or DALI scenes with color temperature values can be defined.", "subtitleLanguage": "", "hostedOnTwentyThree": false, "imageUrl": "https://wagovideo.akamaized.net/public/videos/FLeZ96_8FjFTWGcXz2XSqV/thumbnails/active?quality=1080p&cache-buster=580f93&file-name=349621.3885.1080p.jpeg", "title": "<p>Part 4 – Human Centric Lighting (HCL)</p>", "duration": "2:56" } ,{ "uid": "item_000064Z4", "videoId": "8t6_JAvv5xo7y7pspe9fwD", "caption": "In this video, you will find examples of how to display the recorded fault messages of WAGO Lighting Management.", "subtitleLanguage": "", "hostedOnTwentyThree": false, "imageUrl": "", "title": "<p>Part 5 – Evaluation of Fault Messages</p>", "duration": "1:59" } ,{ "uid": "item_000064Z6", "videoId": "8cWubyx43mqHuRYTt9_ZxJ", "caption": "In this video, we demonstrate how you set up DALI emergency lights for an automatic test system.", "subtitleLanguage": "", "hostedOnTwentyThree": false, "imageUrl": "", "title": "Part 6 – Installation of DALI Emergency Lights with Single Battery", "duration": "2:44" } ,{ "uid": "item_00008ICF", "videoId": "1CLPYS6vvTMLRVzEnHvq9b", "caption": "In this video, we show how you can connect sensors with the DALI-2 protocol to WAGO Lighting Management.", "subtitleLanguage": "", "hostedOnTwentyThree": false, "imageUrl": "https://wagovideo.akamaized.net/public/videos/1CLPYS6vvTMLRVzEnHvq9b/thumbnails/active?quality=1080p&cache-buster=b346a8&file-name=482795.3580.1080p.jpeg", "title": "Part 7 - Sensors with DALI-2 Protocol", "duration": "2:19" } ,{ "uid": "item_000083WZ", "videoId": "8qX7rTA-btJ-7hzGCQVuMJ", "caption": "In this supplement to the video “WAGO Lighting Management Part 4 – Human Centric Lighting (HCL),” we show you how to add dimming curves and setpoint curves to the HCL curve.", "subtitleLanguage": "", "hostedOnTwentyThree": false, "imageUrl": "https://wagovideo.akamaized.net/public/videos/8qX7rTA-btJ-7hzGCQVuMJ/thumbnails/active?quality=1080p&cache-buster=675dce&file-name=545548.3202.1080p.jpeg", "title": "Part 8 – HCL Curves", "duration": "2:45" } ,{ "uid": "item_000083X0", "videoId": "DRUHoR8AyX1YSX8FmrZK9U", "caption": "In this video, we show you how to implement time-dependent toggling of switching functions with the help of schedules.", "subtitleLanguage": "", "hostedOnTwentyThree": false, "imageUrl": "https://wagovideo.akamaized.net/public/videos/DRUHoR8AyX1YSX8FmrZK9U/thumbnails/active?quality=1080p&cache-buster=888bf8&file-name=545550.3251.1080p.jpeg", "title": "Part 9 – Schedules", "duration": "2:06" } ,{ "uid": "item_000091M9", "videoId": "4ua3bEMska6aPe7NxwVhui", "caption": "In this video, we show you the diagnostics options offered by WAGO Lighting Management.", "subtitleLanguage": "", "hostedOnTwentyThree": false, "imageUrl": "https://wagovideo.akamaized.net/private/videos/4ua3bEMska6aPe7NxwVhui/thumbnails/active?quality=1080p&cache-buster=b94932&__token__=exp=1661410079~acl=/private/videos/4ua3bEMska6aPe7NxwVhui/thumbnails/active*~hmac=b727c90d23ce7cc0491601e205320f2861fe518790ca8be431ead2c3810c03be&file-name=748574.3237.1080p.JPEG", "title": "Part 10 - Diagnostics", "duration": "1:58" } ] }

Information Material Download

You will find the following informational material and product overview for lighting management here. Upon request, we can also provide you with the WAGO Lighting Management EPLAN data.

  • Release Notes
  • Manual
  • Bid Texts
  • Circuit Diagrams
  • KNX Interface
  • Application Software

New Product

Convenient and Clear Lighting Control

New Intuitive User Interface for WAGO Lighting Management
Once WAGO Lighting Management has been installed and commissioned, the focus shifts to operation and monitoring while the system runs. The new visualization provides a streamlined user interface for this focus. Whether on a desktop computer, touch panel, tablet or smartphone, the HTML5 Web user interface allows clear and convenient operation of the entire lighting system, accessed with a standard Web browser. The responsive design ensures a perfect display on all end devices. The visualization of the lighting system’s operating data always keeps users informed of the entire lighting system's current status. Simultaneous access to several lighting management controls is also possible via the new visualization interface. In addition to language and color settings, HMI devices, users, rooms and custom profiles can be easily created and managed. Through these capabilities, you can fine-tune lighting to meet incredibly specific needs.

Your Benefits:

  • Intuitive operation
  • User interface customization
  • Cross-controller access via Lighting Management software
