New Column | License Type | M | L |
|---|---|---|---|
IEC 60870 | Server | License NumberServerRedundancy GroupsConnections | 2759-290/211-10002x for -104 and 4x for -1013 for -1044 for -104 |
Client | License NumberConnections (-101, -104)Connections (-103) | 2759-293/211-10001020 | 2759-296/211-10003040 |
DNP3 | Server | License NumberServerConnections | 2759-2290/211-100024 |
Client | License NumberConnections | 2759-2293/211-10004 | 2759-2296/211-10004 |
IEC 61850 | Server | License NumberServerConnectionsLogical Devicesper LD DataSetsper LD Reports CBper LD GOOSE CB | 2759-2240/211-1000152020, each with 50 entries2020 |
Client | License NumberClientConnectionsRead requests per connectionGOOSE Subscriptions | 2759-2243/211-10001203210 GCB | 2759-2246/211-10001303210 GCB |
IEC 60870 + DNP3 + IEC 61850 | Bundle License Number | DRM: 2759-2253/211-1000 | |
Total number of telecontrol objects | 2500 | 5000 |
IEC 60870: IEC 60870-5-101, -104 Slave, IEC 60870 -5-101, -103, -104 Master, 2 slave instances (IEC104) or 4 slave instances (IEC101) possible, 1 … 4 Multi-Master client connections (independent connections after Edition 1) or Multi-Link (redundancy after Edition 2) per slave, IP address filter (white list)1 … 16 ASDU addresses configurable, scalable telegram length: 64 … 253 bytes, freely configurable platform with up to 2000 or 5000 objects per station (depending on hardware and license), direct execution of commands (Direct Operate) or selection and execution (Select before Operate), command lock for single and double commands and aging management, support for count value modes A … D, optional command responses for single and double commands, 8 … 256 kByte of historical data (remanent data storage on SD card possible), IEC 103 Master: Receives error messages and saves them in COMTRADE format, IEC 101/104 Slave: File transfer (TK 120 – 126), time synchronization via NTP or TK 103Import/export function of data point lists in CSV format, optional TLS encryption for IEC 104 Slave (TLS 1.2), DNV certification (IEC 60870-5-104 Slave)
IEC 61850: IEC 61850 MMS Server and Client, IEC 61850 and IEC 61400-25 Server, Edition 1 and Edition 21 server with up to 20 logical devices (LD), 1 client with up to 20 server connections, freely configurable platform with up to 2000 or 5000 objects per station (depending on hardware and license), buffered and unbuffered reporting, GOOSE publisher and subscriber, Server: Max. 20 data sets with max. 50 objects for each LD, server: Max. 20 RCB for each LDClient: Max. 32 requests per connection, client: Max. 32 data sets with 100 entries each, free extension of the data model with own LN, CDC, DO and DA, supported input formats: ICD, SCD, SSD and CID files, supported export formats: ICD and CID files, optional TLS encryption for server (TLS 1.2)
DNP 3DNP3 outstation (server), DNP3 master (client)1 … 4 master connections, freely configurable for serial and ETHERNET, freely configurable platform with up to 2000 or 5000 objects per station (depending on hardware and license), IP address filter (white list) for ETHERNET connections, event buffer (<= 100000 events) in RAM or remanent storage on SD memory card, automatic or manual start index assignment for objects, scalable hysteresis of the master’s analog inputs (object group 34), direct execution of commands (Direct Operate) or selection and execution (Select before Operate), 8/16-bit configurable object qualifier, unsolicited messages (modes A … E) with optional class-specific transmission parameters, outstation: File transfer for serial and ETHERNET (object group 70)Time synchronization via NTP or DNP3 (object group 50), import/export function of data point lists in CSV formatImport/export function of configuration and data point lists in “DNP3 Device Profile” formatOptional TLS encryption for outstation (TLS 1.2)
