ENCLOSURES

The installer connectors need to be within a suitable enclosure. According to BS 7671, “every connection and
termination must be enclosed irrespective of the nominal voltage”. The WAGOBOX® and WAGOBOX® Light junction boxes meet BS EN 60670-01 and BS EN 60670-22. If you are in anyway unsure about how to connect a circuit, please consult a qualified electrician.

WAGO Gelboxe's

WAGO’s Gelbox - IPX8

When moisture threatens the terminals blocks, the WAGO Gelbox makes electrical installations watertight – quickly, easily and reliably. The WAGO Gelbox utilizes high-quality, silicone-free gel from Cellpack, making this enclosure ready to use in any branch of industry.

Data Sheet

WAGOBOX® 221-4, WAGOBOX®, XL & XLA

The WAGOBOX® range is suitable for MF application when using our 221, 2273, 773 and 222 Series connectors.Please see data sheet for more info.

WAGOBOX® 221-4

Suitable for MF applications when using WAGO's 221 series (4mm²).

Dimensions: 39 x 44 x 108mm

Part No. 207-3301 (PU 1)
WAGOBOX® Fixing Buttons Part No. 207-9309 (PU 10)


WAGOBOX®

Suitable for MF applications when using WAGO's 222 & 773 series.

Dimensions: 39 x 44 x 108mm

Part No. 207-3302 (PU 1)
WAGOBOX® Fixing Buttons Part No. 207-9309 (PU 10)

WAGOBOX® XL

Suitable for MF applications when using WAGO's 221 or 2273 series.

Dimensions: 162 x 115 x 55mm

Part No. 207-3304 (PU 1)
WAGOBOX® Fixing Buttons Part No. 207-9309 (PU 10)

WAGOBOX® XLA

Suitable for MF applications when using WAGO's 222 or 773 series.

Dimensions: 162 x 115 x 55mm

Part No. 207-3305 (PU 1)
WAGOBOX® Fixing Buttons Part No. 207-9309 (PU 10)

WAGOBOX® Light

The installer connectors need to be within a suitable enclosure. According to BS 7671, “every connection and termination must be enclosed irrespective of the nominal voltage”. The WAGOBOX® Light junction box meet BS EN 60670-01 and BS EN 60670-22. The WAGOBOX® Light junction box is for use with our 224, 260 and 294 Series connectors.

WAGOBOX® LIGHT

Suitable for lighting applications using WAGO's 224 series.

Dimensions: 39 x 29 x 95mm

Part No. 207-3303 (PU 1)
WAGOBOX® Fixing Buttons Part No. 207-9309 (Pu 10)

WAGOBOX® Capsule

The WAGOBOX® Capsule is rated up to IP68 (BS EN 60529) when used with suitable glands (sold separately). The WAGOBOX® Capsule can be installed inside, outside or even directly buried into soil. The WAGOBOX® Capsule is robust and manufactured from UV resistant materials allowing installation in locations that are sunny, wet, dusty or muddy.

WAGOBOX® Capsule

Dimensions: Lid Diameter 92mm, Height 122mm, Body width 85mm

Part No. 207-3307 (Grey, PU 1)
Part No. 207-3308 (Black, PU 1)
Part No. 207-3306 (Clear, PU 1)

Accessories:
Lid Plate - Part No. 207-9304 (PU 1)
Side Plate - Part No. 207-9305 (PU 1)
Grey Capsule Bracket - Part No. 207-9302 (PU 1)
Black Capsule Bracket - Part No. 207-9303 (PU 1)
Grey Post Bracke t- Part No. 207-9306 (PU 1)
Black Post Bracket - Part No. 207-9303 (PU 1)

Abox 060 Polystyrene (IP68)

Polystyrene Abox 060 - Includes 5 x 221-413

Dimensions: 110 x 110 x 67mm

Part No: 60290788
