PCB Connection Technology: Easy Configuration

WAGO’s Smart Designer Configurator is a free 3D online engineering tool for WAGO’s electrical interconnection and automation technology products. With this tool, you can design PCB terminal blocks and connectors to your exact specifications. Connection components can be customized quickly and easily based on the following parameters:

• Pole number

• Pin spacing

• Conductor cross-section

• Color

• Actuation type

• Solder pin arrangement

• Coding

• Marking

Once the configuration is generated, you can export data sheets and 3D models in various formats, including AutoCAD, DXF, Inventor, NX, STP and more. This ensures that you have all the necessary data for further engineering and documentation.

To quickly assess whether the configured item meets your individual application needs, the WAGO Smart Designer Configurator provides a direct request process for suitable component samples. You have two options:

1. 48-hour delivery from the preferred sample program, with recommendations for configuration-like items

2. 7-day delivery of the exact component sample

The planning and design-in process is an essential step in configuring PCBs. PCB connection technology plays a crucial role in this. Our digital PCB services help you find the right product for your PCB.

With our digital services, we support PCB planning and design. These include the product finder for PCB connectors, digital PCB data and PCB sample dispatch.

With our digital services, you can find the right retailer for WAGO products in your area or order the required components directly online around the clock. In addition, the services offer all important information and product data.

WAGO's lever technology for PCB terminal blocks and pluggable PCB connectors provides safe, intuitive and tool-free operation.

WAGO offers a wide portfolio of extremely compact PCB terminal blocks and connectors with levers, including products designed for power electronics.

With the MULTI CONNECTION SYSTEM (MCS), WAGO offers end-to-end system wiring for conductor cross-sections from 0.08 to 25 mm² with pluggable PCB connectors.
